WM18 Milling Machine - R8 with DRO

    3260NDRO

    £2,695.00 Inc. VAT

    • High quality R8 variable speed mill
    • Long table (840mm)
    • Very quiet operation
    • Precision spindle & fine feed
    • Tested for Accuracy - Report Supplied
    • Excellent Spare-Parts Availability
    • Includes FREE accessories
    • 12-Month Warranty
    • Fast & FREE DELIVERY to UK mainland
    • Optional stand sold separately >
    • Also available without DRO >
    • Questions & Support on Tel: 01428 682929

    More details

    product description

    Now with R8 spindle taper, large sized table, infinitely variable speed the WM18 is an extremely flexible and robust mill.

    Features include:

    • Dovetail column slide for positive head location during elevation and decent
    • Tapered gibs to all slideways
    • Digital depth gauge to quill with metric/imperial calibrations
    • Back gear ensures maximum torque in low speed range
    • Locks to head, columns and slideways
    • Precision spindle supported on taper roller bearings
    • Head tilting plus or minus 90°
    • Rack and pinion drilling action
    • Reversible motor
    • Interlock chuck guard
    • As with all Warco milling machines, this machine has metal gears.

    Includes the following FREE accessories:

    • Drawbar 7/16" UNF
    • Drill chuck 13mm
    • Arbor for drill chuck
    • Tool box and maintenance tools



    Full Specification:

    WM18 Mill

    (Product code: 3260)

    Product Dimensions:



    Weight220KG
    Length x Width x Height1230 X 710 X 1190mm
    Tray Length x Depth590 x 670

    Shipping Dimensions


    Length x Width x Height 985 x 745 x 1125mm

    Power/Motor


    Motor size1.1kw
    Power Transfer (GH) gearbox or (VS) variable speedVS
    Voltage (240v single) (440v 3 Phase)240V
    Fitment (Plug connection type)3 Pin Plug
    Current50hz 5.2A
    Spindle speeds (No: and achievable speeds)50-1100 / 150-3000rpm

    Main Specifications


    Table size840 x 210mm
    Longitudinal travel (X)590mm
    Cross Table travel (Y)220mm
    Head Travel or Knee (Z)370mm
    Quill/Spindle stroke 70mm
    Distance spindle to table465mm
    Throat (Spindle middle to Column)180mm
    Table height from base 210mm
    Spindle Taper size and threadR8 7/16 unf
    Head tilt left to right and Head tilt front to back90-90 (45-45 calibrated)
    Drilling capacity16mm
    Milling capacity20mm
    Spindle Bearing typeTaper Roller

    Other Specifications


    Country of originChina
    Warranty12 Months
    Approximated assembly and setup time30 mins
    CE approved CertificateM.2016.201.Y1869

    Additional products


    Optional stand3262DL
    Optional power feed3205.18
    Optional Digital Read Out Kit8123 dro
    X axis scale (left to right)600mm
    Y axis scale (forward to back)250mm
    Z axis scale (head)400mm
    Tee Nut size and no of slotsA=12 B=17.5 C=6.5 D=7.5mm (3 SLOTS) M12
    Machine/Stand Hole positionsA=380 B=335 C=130 D=128mm

    Please note that DC motors do not run at full speed in reverse.

    product download

    Machine Data sheet 3260N

    Machine Data Download (266.29k)

    Machine Data sheet 3260NP

    Machine Data Download (267.83k)

    Machine Data sheet 3260NDRO

    Machine Data Download (267.25k)
